2015-2017 5.0L Mustang Phase 1/2 RHD ROUSHcharger Kit
SECTION A – DISASSEMBLY
1316-RHD-AA 12152016 16 800.59.ROUSH
28. Remove the lter from the airbox. Remove the
mounting bolt at the side of the airbox (10 mm
socket). Pull up and remove the lower airbox from
the vehicle.
29. Disconnect the brake aspirator.
30. Disconnect the throttle body electrical connector.
Pull the red locking tab back; press the black
release tab to disengage the lock.
31. Unlock the green connector and disconnect
the evaporative emission canister purge valve
(EECPV) tube and electrical connector (green).
Remove the EECPV tube retainer from the front
left hand cam cover. Disconnect the remainder
of the tube at the tting located behind the inner
passenger side fender. A fuel line removal tool will
be necessary to release the connector. Remove
from vehicle and set it aside. Both connectors will
be transferred to the new line in Hardware Kit E
Wiring. (Pictures show left hand drive model. Line
routing may vary.)
