2015-2017 5.0L Mustang Phase 1/2 RHD ROUSHcharger Kit
SECTION A – DISASSEMBLY
1316-RHD-AA 12152016 18 800.59.ROUSH
32. Remove the PCV purge line from the intake
manifold and RH cam cover. This line will not be
reused.
33. Disconnect the fuel supply hose from the fuel rail.
NOTE: Use a rag to catch any excess fuel during
disconnection. Use a cap, tape or other suitable
method to block the rail opening from contaminants.
34. Disconnect the brake booster vacuum hose from
the intake manifold. This port is located directly
behind the throttle body.
35. Move the LH heater hose aside from the support
bracket on top of the LH cylinder head.
36. Remove the two (2) nuts that secure the brake
boost vacuum hose and heater hose support
bracket to the LH cylinder head.
37. Disconnect the brake boost vacuum hose from
the port at the rewall (driver side of vehicle).
