2015-2017 5.0L Mustang Phase 1/2 RHD ROUSHcharger Kit
SECTION A – DISASSEMBLY
1316-RHD-AA 12152016 23 800.59.ROUSH
Degas hose from bottom of bottle
51. Remove the two (2) mounting bolts (10 mm
socket) and remove the engine coolant degas
bottle.
52. Disconnect the clamp on the end of the upper
radiator hose at the radiator. Use a rag to catch
excess coolant. On the thermostat housing end
of the hose, push the clip down on the connector
and remove the upper radiator hose from the
vehicle.
Some coolant will still be inside the hose. Use a
rag to catch coolant when removing the hose.
53. Loosen the water pump bolts.
54. Remove the front end accessory drive (FEAD) belt.
Rotate the FEAD tensioner counter-clockwise to
release the belt tension and remove the belt. Set
the belt aside as it will be reused.
