ROUSH 422011 - Install Factory MAF Sensor into MAF Tube; Install Upper Airbox Cover; Section D - Installation; Induction Resonance Tube Delete Grommet Installation

2015-2017 5.0L Mustang Phase 1/2 RHD ROUSHcharger Kit
SECTION C – SUBASSEMBLY
1316-RHD-AA 12152016 53 800.59.ROUSH
7. Transfer and install the factory MAF sensor into
the MAF tube assembly using the original MAF
sensor bolts (M4 X 0.7 X 10) and tighten with a
T-20 Torx bit. Torque the screws to 1.8–2.2 Nm.
Be careful not to over tighten these screws.
Wiggle the MAF sensor to ensure that it is
properly fastened.
8. Install the upper airbox cover (1315-9643) on
the airbox tray. Using a T-30 Torx head bit, install
six (6) bolts (W506976) from Hardware Kit A
(1315-TVSHKA).
9. Remove the grommets and sleeves from the
factory lower airbox. Install the grommets and
sleeves onto the new airbox assembly.
TIP: Remove the center bushing while installing the
rubber grommet through the hole in the tab. Re-install
the center bushing once the grommet is fully seated.
10. Remove the rubber mounting isolator from the
bottom of the factory airbox and install it onto
the mount on the bottom of the new airbox in the
same orientation.
