DescriptionSetting
Configure the port as an 802.1X authenticator or supplicant. The
following options are available:
• Disabled: No 802.1X controls are applied to this port.
• Authenticator (Port-based): Only one of the attached MAC
hosts must be authorized for all hosts to be granted access to
the network.
• Authenticator (MAC-based): Each MAC host is individually
authenticated.
• Supplicant: The port acts as a supplicant to an upstream
authenticator. Configure a port as Supplicant if the port is a
Trunk Port used to connect the AP to a LAN switch.
See Working with 802.1X on Wired Ethernet Ports on page 120 for
more information.
802.1X
Untag ID: Enter a valid VLAN ID in this field to segment traffic
arriving on this port to a specific VLAN. Default is 1. Valid VLAN
entries are 1-4094.
Members: Displays the VLAN membership of the port. (Membership
is configurable only for the General port type.)
Refer to Working with Port-Based VLANs on page 119 for more
information.
VLAN
When this option is enabled for an Ethernet port, additional
information is encapsulated in DHCP option 82 and inserted into
DHCP request packets.
Current format of option 82 is:
Circuit ID sub-option: ETH:<IFNAME>:<VLAN>:N/A:
<MODEL>:<HOSTNAME>:<DEVMAC>
This option supports the ability for a service provider to allocate IP
addresses intelligently by considering information on the origin of
the IP allocation request.
Insert DHCP
Option 82
When this option is Enabled, the AP attempts to identify client
devices by their operating system, device type and host name, if
available.
Client
Fingerprinting
3. Click Update Settings to save your changes.
118
ZoneFlex Indoor Access Point Release 104.0 User Guide
Configuration
Configuring the AP
