Figure 10: 7372 rear panel
ZoneFlex 7372-E
The ZoneFlex 7372-E is a best-performing, concurrent dual-band, mobile-ready,
two-stream 802.11n AP, with two RP-SMA connectors used to support dual-band
2.4GHz and 5GHz external antennas.
NOTE The 100.x AP base images support standalone mode and FlexMaster (FM)
WLAN manager operation. The SmartZone software-compatible images only support
SCG, SZ and vSZ controllers. The ZD-compatible images only support ZD controllers.
NOTE The 7372-E requires a minimum of AP base image 100.0.0 and later to operate,
or SCG 2.1 and later, vSZ 2.5 and later, SmartZone software 3.2 and later, or ZD 9.6
and later to operate.
The 7372-E includes five LEDs on its front panel and buttons and connectors on its rear
panel.
Front Panel
The following figure shows the top view of the 7372-E. For a description of each front
panel part, refer to the table below.
ZoneFlex Indoor Access Point Release 104.0 User Guide
25
Introduction
Getting to Know the AP Features
