the associated LAN connections, as defined by Environment A of the IEEE 802.3af
Standard.
ZoneFlex R600
The R600 is a high-performance 3x3:3 802.11ac dual-band AP designed for medium-
to high-density wireless networks.
NOTE The R600 AP requires a minimum of AP base image 100.0.0 and later to operate,
or SCG 2.5.1 and later, vSZ 3.0 and later, SmartZone software 3.2 and later, or ZD 9.8.1
and later to operate.
The R600 includes five LEDs on its front panel and buttons and connectors on its rear
panel.
Front View Features
The following figure shows the top view of the R600. For a description of the front panel
LEDs, refer to the table below.
ZoneFlex Indoor Access Point Release 104.0 User Guide
57
Introduction
Getting to Know the AP Features
