Navigating the Web Interface
You can manage the AP through a web browser-based user interface that is accessible
from any networked computer or mobile device.
The following figure and table describe the ZoneFlex Access Point web interface
components.
Figure 45: Elements of the Ruckus Wireless AP Web Interface
Table 41: Ruckus Wireless AP Web interface elements
DescriptionElementNo.
Under each category (Status, Configuration,
etc.) are options that, when clicked, open the
related workspace in the area to the right.
Menu1
Contains additional options for the
configuration page. For example, the
Configuration > Wireless page includes one
tab for common wireless configuration and
eight tabs for each of the available WLANs.
Tabs2
Click this button to log out of the AP.LOGOUT Button3
Click this button to open a help window with
information related specifically to the options
currently displayed in the workspace.
Help Button4
