ZoneFlex R710
The R710 is a high-capacity, high-performance, four-stream, dual-band 802.11ac Wave
2 AP with adaptive antenna technology for carriers and enterprises.
The R710 has a USB port on its bottom panel. The USB port is intended for low-power
devices such as BLE (Bluetooth low energy) beacons. The maximum power that the
USB port can supply is 0.5W. Refer to Appendix A: AP Support for Bluetooth Low Energy
Devices on page 148 for more information.
The R710 can use the link aggregation control protocol (LACP) to control the bonding
of two 1Gbps physical Ethernet ports together to form a single logical channel. Refer to
Appendix B: Configuring Link Aggregation (LACP) for AP Backhaul on page 149 for
instructions on bonding the two Ethernet ports using LACP.
NOTE The 100.x AP base images support standalone mode and FlexMaster (FM)
WLAN manager operation. The SmartZone software-compatible images only support
SCG, SZ and vSZ controllers. The ZD-compatible images only support ZD controllers.
NOTE The R710 AP requires a minimum of AP base image 100.2.0 and later to operate,
or SmartZone software 3.1.1 and later, or ZD 9.12 and later to operate.
NOTE The R710 is not supported by the ZoneDirector 1100.
The R710 includes five LEDs on its front panel, and buttons and connectors on its bottom
panel.
Front View Features
The following figure shows the top view of the R710. For a description of the front panel
LEDs, refer to the table below.
ZoneFlex Indoor Access Point Release 104.0 User Guide
65
Introduction
Getting to Know the AP Features
