Figure 12: 7372-E rear panel
Table 9: 7372-E rear panel elements
DescriptionItem Name
Pressing, and then quickly releasing this
internal button reboots the AP. Pressing
and holding it for six seconds resets the
AP to factory default settings.
CAUTION! Resetting the AP to factory
default settings erases all previously
configured settings.
RST Button
One RJ-45 port for a 10/100/1000 PoE
(Power over Ethernet, 802.3af) connection.
10/100/1000+PoE Port
One RJ-45 port for a 10/100 connection.10/100 Port
Connect the power adapter (12
VDC/1.25A) to this socket. Power can also
be supplied via the 10/100/1000 PoE port.
Power
Connect to dual-band 2.4GHz and 5GHz
external antennas.
RP-SMA connectors
ZoneFlex 7982
The ZoneFlex 7982 is a high-capacity, high-performance, three-stream dual-band
802.11n AP for carriers and enterprises.
NOTE The 100.x AP base images support standalone mode and FlexMaster (FM)
WLAN manager operation. The SmartZone software-compatible images only support
SCG, SZ and vSZ controllers. The ZD-compatible images only support ZD controllers.
NOTE The 7982 requires a minimum of AP base image 100.0.0 and later to operate,
or SCG 1.1 and later, vSZ 2.5 and later, SmartZone software 3.2 and later, or ZD 9.4
and later to operate.
The 7982 includes five LEDs on its front panel and buttons and connectors on its rear
panel.
Front Panel Features
The following figure shows the top view of the 7982. For a description of each front panel
part, refer to the table below.
28
ZoneFlex Indoor Access Point Release 104.0 User Guide
Introduction
Getting to Know the AP Features
