DescriptionItem Name
Pressing, and then quickly releasing this
internal button reboots the AP. Pressing
and holding it for six seconds resets the
AP to factory default settings.
CAUTION! Resetting the AP to factory
default settings erases all settings that you
configured previously.
RESET Button
NOTE Class 4 device. Some PoE+ switches reserve 30W for Class 4 device by default.
Ethernet Port LEDs
Refer to the following table for descriptions of Ethernet port LEDs and their behaviors.
The LEDs are not visible once the AP is installed.
Table 12: Behavior of Ethernet port LEDs on 7982
DescriptionLED
Not connectedOff
Connected to 10Mbps deviceAmber + Green
Connected to 100Mbps deviceAmber
Connected to 1000Mbps deviceGreen
WARNING! For units with Power over Ethernet (PoE). These products and all
interconnected equipment must be installed indoors within the same building, including
the associated LAN connections, as defined by Environment A of the IEEE 802.3af
Standard.
ZoneFlex H500 Wall Switch
The H500 is a high-capacity, high-performing, two-stream, dual-band, 802.11ac,
multimedia Wi-Fi AP wall switch with adaptive antenna technology for carriers and
enterprises.
NOTE The 100.x AP base images support standalone mode and FlexMaster (FM)
WLAN manager operation. The SmartZone software-compatible images only support
SCG, SZ and vSZ controllers. The ZD-compatible images only support ZD controllers.
32
ZoneFlex Indoor Access Point Release 104.0 User Guide
Introduction
