NOTE The H500 AP requires a minimum of AP base image 100.1.0 and later to operate,
or SCG 3.1 and later, vSZ 3.0 and later, SmartZone software 3.2 and later, or ZD 9.10
and later to operate.
NOTE The H500 is not supported by the ZoneDirector 1100.
The H500 has many options:
• It can be mounted on a standard USA- or EU-style single-gang wall outlet box.
• It can be powered by a customer-supplied IEEE 802.3af- or 802.3at-compliant PoE
switch or injector, or can be powered by an optional customer-ordered DC power
adapter.
• It has side cutouts for one or two bypass cables. The mounting bracket has locating
hooks to keep the bypass cables aligned with the cutouts when attaching the H500
to the mounting base.
• It can have a low-power (0.5W or less) customer-supplied USB device plugged in.
The USB port is intended for low-power devices such as BLE (Bluetooth low energy)
beacons.
The H500 has four LEDs, one RJ-45 connector, and a reset button on its rear panel,
and has one USB port (refer to Appendix A: AP Support for Bluetooth Low Energy
Devices on page 148, four RJ-45 connectors, and one DC power connector on its bottom
panel.
About Peripheral Devices
The H500 can supply power to USB devices and PoE-powered devices, and the power
supplied depends on the PoE power supplied to the H500.
• The USB port is intended for low-power devices such as BLE beacons. The maximum
power that the USB port can supply is 0.5W.
• The LAN1+PoE port is intended for PoE-powered peripheral devices such as IP
telephones.
For a description of the input and output power options, refer to the table below.
Table 13: H500 power options and available power out for PoE out and USB
Power Available for PoE Out and USBH500 Power Source
4W total802.3af PoE
12.95W PoE Out (802.3af Class 3) and
0.5W USB
802.3at PoE
12.95W PoE Out (802.3af Class 3) and
0.5W USB
DC power adapter (sold separately)
