Front Panel Features
The following figure shows the front view of the H500.
Figure 15: H500 front view
Rear Panel Features
The following figure shows the rear panel of the H500. For a description of each rear
panel element, refer to the table below.
1
2
3
4
5
34
ZoneFlex Indoor Access Point Release 104.0 User Guide
Introduction
Getting to Know the AP Features
