Figure 16: H500 rear view
Table 14: H500 rear panel elements
DescriptionLED
• Off: Off.
• Red: Boot up in process.
• Flashing Green: No routable IP address
• Green: On.
PWR
• Off: The AP is not being managed by a
Ruckus Wireless controller (standalone
mode).
• Green: The AP is being managed by a
Ruckus Wireless controller.
• Slow flashing green (one flash every two
seconds): The AP is being managed by
a Ruckus Wireless controller, but is
currently unable to communicate with
the controller.
• Fast flashing green (two flashes every
second): The AP is being managed by
a Ruckus Wireless controller and is
currently receiving configuration settings
(provisioning) or an image update.
CTL
• Off: The 2.4GHz WLAN service is down.
• Green: The WLAN service is up, at least
one client is associated, and signal
quality is good (RSSI >= 15).
• Amber: The WLAN service is up but no
clients are associated.
2.4GHz WLAN
ZoneFlex Indoor Access Point Release 104.0 User Guide
35
Introduction
Getting to Know the AP Features
