ZoneFlex R700
The R700 is a high-capacity, high-performance, three-stream, 802.11ac dual-band AP
with adaptive antenna technology for carriers and enterprises.
NOTE The R700 AP requires a minimum of AP base image 100.0.0 and later to operate,
or SCG 2.5.1 and later, vSZ 3.0 and later, SmartZone software 3.2 and later, or ZD 9.7.1
and later to operate.
The R500 includes five LEDs on its front panel and buttons and connectors on its rear
panel.
Front View Features
The following figure shows the top view of the R700. For a description of the front panel
LEDs, refer to the table below.
Figure 33: R700 top view
Table 32: R700 front panel LEDs
DescriptionLED
• Off: Off.
• Red: Boot up in process.
• Flashing Green: No routable IP address
• Green: On.
PWR
ZoneFlex Indoor Access Point Release 104.0 User Guide
61
Introduction
Getting to Know the AP Features
