Figure 14: 7982 rear panel
Table 11: 7982 rear panel elements
DescriptionItem Name
One RJ-45 port for a 10/100/1000 PoE
(Power over Ethernet, 802.3af/at)
connection (Note).
ETHERNET + PoE Port
One RJ-45 port for a 10/100/1000
connection.
ETHERNET Port
Connect the power adapter (12
VDC/1.25A) to this socket. Power can also
be supplied via the ETHERNET + PoE port.
12V 1.5A Power Socket
ZoneFlex Indoor Access Point Release 104.0 User Guide
31
Introduction
Getting to Know the AP Features
