DescriptionLED
• Off: The AP is operating in standalone
mode or operating as a root AP (RAP)
or a non-mesh AP.
• Green: The AP is functioning as a Mesh
AP (MAP), and the wireless signal to its
uplink AP is good.
• Fast flashing green (two flashes every
second): The AP is functioning as a
Mesh AP (MAP), and the wireless signal
to its uplink AP is fair.
• Slow flashing green (one flash every two
seconds): Mesh networking is enabled,
but the AP is still searching for a mesh
uplink.
AIR LED
• Off: The WLAN service is down.
• Green: The WLAN is up and at least
one client is associated.
• Amber: The WLAN is up. No clients are
associated.
2.4GHz LED
• Off: The WLAN service is down.
• Amber: The WLAN is up, but no clients
or downlink MAPs are
associated/connected.
• Green: The WLAN is up and at least
one client is associated. No downlink
MAPs are connected.
• Slow flashing green (one flash every two
seconds): The WLAN is up and at least
one downlink MAP is connected. No
clients are associated.
• Fast flashing green (two flashes every
second): The WLAN is up, at least one
downlink MAP is connected, and at
least one client is associated.
5GHz LED
Rear Panel Features
The following figure shows the rear panel of the 7982. For a description of each rear
panel part, refer to the table below.
