Figure 35: R710 front view
Table 35: R710 front panel LEDs
DescriptionLED
• Off: Off.
• Red: Boot up in process.
• Flashing Green: No routable IP address
• Green: On.
PWR
• Off: The AP is not being managed by a
Ruckus Wireless controller (standalone
mode).
• Green: The AP is being managed by a
Ruckus Wireless controller.
• Slow flashing green (one flash every two
seconds): The AP is being managed by
a Ruckus Wireless controller, but is
currently unable to communicate with
controller.
• Fast flashing green (two flashes every
second): The AP is being managed by
a Ruckus Wireless controller and is
currently receiving configuration settings
(provisioning) or an image update.
CTL
• Off: The AP is operating in standalone
mode or operating as a root AP (RAP)
or a non-mesh AP.
• Green: The AP is functioning as a Mesh
AP (MAP), and the wireless signal to its
uplink AP is good.
• Fast flashing green (two flashes every
second): The AP is functioning as a
Mesh AP (MAP), and the wireless signal
to its uplink AP is fair.
• Slow flashing green (one flash every two
seconds): Mesh networking is enabled,
but the AP is still searching for a mesh
uplink.
AIR
66
ZoneFlex Indoor Access Point Release 104.0 User Guide
Introduction
Getting to Know the AP Features
