DescriptionLED
• Off: The WLAN service is down.
• Green: The WLAN is up and at least
one client is associated.
• Amber: The WLAN is up. No clients are
associated.
2.4G
• Off: The WLAN service is down.
• Amber: The WLAN is up, but no clients
or downlink MAPs are
associated/connected.
• Green: The WLAN is up and at least
one client is associated. No downlink
MAPs are connected.
• Slow flashing green (one flash every two
seconds): The WLAN is up and at least
one downlink MAP is connected. No
clients are associated.
• Fast flashing green (two flashes every
second): The WLAN is up, at least one
downlink MAP is connected, and at
least one client is associated.
5G
Bottom Panel
The bottom panel of the R710 includes the following:
• one 10/100/1000 PoE In Ethernet port
• one 10/100/1000 Ethernet port
• one 12VDC 2A power socket
• one reset button
• one USB port
ZoneFlex Indoor Access Point Release 104.0 User Guide
67
Introduction
Getting to Know the AP Features
