Figure 34: R700 rear panel
Table 33: R700 Rear panel element descriptions
DescriptionLabel
One RJ-45 port for a 10/100/1000 PoE
(Power over Ethernet, 802.3af/at)
connection. (The R700 is a Class 3 device.)
ETHERNET + PoE Port
One RJ-45 port for a 10/100/1000
connection.
ETHERNET Port
Connect the power adapter (12
VDC/1.25A) to this socket. Power can also
be supplied via the ETHERNET + PoE port.
12V 1.5A Power Socket
Pressing, and then quickly releasing this
internal button reboots the AP. Pressing
and holding it for six seconds resets the
AP to factory default settings.
NOTE Resetting the AP to factory default
settings erases all settings that you
configured previously.
RESET Button
Ethernet Port LEDs
Table 34: Behavior of Ethernet port LEDs on the R700
DescriptionLED
Not connectedOff
Connected to 10Mbps deviceAmber + Green
Connected to 100Mbps deviceAmber
Connected to 1000Mbps deviceGreen
WARNING! For units using Power over Ethernet (PoE). These products and all
interconnected equipment must be installed indoors within the same building, including
the associated LAN connections, as defined by Environment A of the IEEE 802.3af
Standard.
