Figure 30: R510 rear panel
Table 27: R510 Rear panel element descriptions
DescriptionLabel
Pressing, and then quickly releasing this
button reboots the AP. Pressing and
holding it for six seconds resets the AP to
factory default settings.
NOTE Resetting the AP to factory default
settings erases all settings that you
configured previously.
RESET Button
One RJ-45 port for a 10/100/1000 PoE
(Power over Ethernet, 802.3af/at)
connection. (The R510 is a Class 3 device.)
PoE Port
One RJ-45 port for a 10/100/1000
connection.
Ethernet Port
Connect the power adapter (12
VDC/1.25A) to this socket. Power can also
be supplied via the 10/100/1000 PoE port.
12VDC
The R510 can have a low-power (0.5W or
less) customer-supplied USB device
plugged in. The USB device is hidden after
the R510 is attached to its mounting base.
USB Port
Ethernet Port LEDs
Table 28: Behavior of Ethernet port LEDs on the R510
DescriptionLED
Not connectedOff
Connected to 10Mbps deviceAmber + Green
Connected to 100Mbps deviceAmber
Connected to 1000Mbps deviceGreen
WARNING! For units using Power over Ethernet (PoE). These products and all
interconnected equipment must be installed indoors within the same building, including
56
ZoneFlex Indoor Access Point Release 104.0 User Guide
Introduction
Getting to Know the AP Features
