Enable and modify LACP rate & distribution algorithm:
:set bond bond0 add eth0
:set bond bond0 add eth1
:set bond bond0 xmit-hash 1
:set bond bond0 lacp-rate 1
Apply VLANs untag ID to bonded interface:
:set interface bond0 type trunk untag 777
Caveats
• As of this writing, the controller and AP web UIs do not expose LACP settings or
configuration. If an AP is configured via AP CLI to bond its Ethernet ports, then any
per-Ethernet port setting in the web UIs are ignored by the AP.
• The R710's 802.3af PoE operating mode, which limits AP functionality so as to remain
within the standard 802.3af PoE power budget, requires that one Ethernet port be
disabled. As such, an AP in 802.3af PoE operating mode cannot be configured to
bond its Ethernet ports with LACP.
NOTE Refer to ZoneFlex R710 AP for a description of the feature and function
limitations imposed under the 802.3af PoE operating mode.
This means LACP is supported as long as the R710 AP is powered via:
• 802.3at PoE+
• Passive PoE injector capable of at least 20W
• 12V DC power supply
NOTE The switch port must support link layer discovery protocol (LLDP) power over
Ethernet/MDI (PoE+) so the R710 can operate in full-power mode.
