DescriptionLED
• Off: The AP is not being managed by a
controller (standalone mode).
• Green: The AP is being managed by a
controller.
• Slow flashing green (one flash every two
seconds): The AP is being managed by
a controller, but is currently unable to
communicate with the controller.
• Fast flashing green (two flashes every
second): The AP is being managed by
a controller and is currently receiving
configuration settings (provisioning) or
an image update.
DIR LED
• Off: The WLAN service is down.
• Green: The WLAN service is up and at
least one client is associated.
• Amber: The WLAN service is up and no
clients are associated.
2.4G LED (WLAN)
• Off: The WLAN service is down.
• Green: The WLAN service is up and at
least one client is associated.
• Amber: The WLAN service is up and no
clients are associated.
5G LED (WLAN)
Rear Panel Features
The rear panel of the R300 includes one 10/100/1000 PoE Ethernet port, power socket
and reset button. See the table below for a description of each rear panel part.
44
ZoneFlex Indoor Access Point Release 104.0 User Guide
Introduction
Getting to Know the AP Features
