Figure 27: R500 top view
Table 23: R500 front panel LEDs
DescriptionLED
• Off: Off.
• Red: Boot up in process.
• Flashing Green: No routable IP address
• Green: On.
PWR
• Off: The AP is not being managed by a
controller (standalone mode).
• Green: The AP is being managed by a
controller.
• Slow flashing green (one flash every two
seconds): The AP is being managed by
a controller, but is currently unable to
communicate with the controller.
• Fast flashing green (two flashes every
second): The AP is being managed by
a controller and is currently receiving
configuration settings (provisioning) or
an image update.
DIR
• Off: The AP is operating in standalone
mode or operating as a root AP (RAP)
or a non-mesh AP.
• Green: The AP is functioning as a Mesh
AP (MAP), and the wireless signal to its
uplink AP is good.
• Fast flashing green (two flashes every
second): The AP is functioning as a
Mesh AP (MAP), and the wireless signal
to its uplink AP is fair.
• Slow flashing green (one flash every two
seconds): Mesh networking is enabled,
but the AP is still searching for a mesh
uplink.
AIR
• Off: The WLAN service is down.
• Green: The WLAN is up and at least
one client is associated.
• Amber: The WLAN is up. No clients are
associated.
2.4G
50
ZoneFlex Indoor Access Point Release 104.0 User Guide
Introduction
Getting to Know the AP Features
