DescriptionLED
• Off: The WLAN service is down.
• Amber: The WLAN is up, but no clients
or downlink MAPs are
associated/connected.
• Green: The WLAN is up and at least
one client is associated. No downlink
MAPs are connected.
• Slow flashing green (one flash every two
seconds): The WLAN is up and at least
one downlink MAP is connected. No
clients are associated.
• Fast flashing green (two flashes every
second): The WLAN is up, at least one
downlink MAP is connected, and at
least one client is associated.
5G
Rear Panel
The rear panel of the R600 includes one 10/100/1000 PoE Ethernet port, 10/100/1000
Ethernet port, power socket and reset button. See the table below for a description of
each rear panel part.
ZoneFlex Indoor Access Point Release 104.0 User Guide
59
Introduction
Getting to Know the AP Features
