DescriptionLabel
The R710 can have a low-power (0.5W or
less) customer-supplied USB device
plugged in. The USB device is hidden after
the R710 is attached to its mounting base.
USB Port
Ethernet Port LEDs
Table 37: Behavior of Ethernet port LEDs on the R710
DescriptionLED
Not connectedOff
Connected to 10Mbps deviceAmber + Green
Connected to 100Mbps deviceAmber
Connected to 1000Mbps deviceGreen
WARNING! For units using Power over Ethernet (PoE). These products and all
interconnected equipment must be installed indoors within the same building, including
the associated LAN connections, as defined by Environment A of the IEEE 802.3af
Standard.
70
ZoneFlex Indoor Access Point Release 104.0 User Guide
Introduction
