7.3.3 NMEA Error Code Descriptions
The error codes in the NMEA data from the NMEA Module identify the NMEA module and its port that has
the error. These errors occur when either the data format or speed does not match the received data, or
the received data is corrupted.
The error message is in the format NerrorXX, where N is the NMEA ID and XX is the code as listed
below.
Code 8-Port NMEA Module 4-Port NMEA Module
A 232/422 Output 232/422 Output
B 422 Input 422 Input
C Input 1 Input 1
D Input 2 Input 2
E Input 3 Input 3
F Slave/Master Link Input 4
SA Output to Slave NA
SB Input Port 4 NA
SC Input Port 5 NA
SD Input Port 6 NA
SE Input Port 7 NA
SF Input Port 8 NA
Table 7-3 - NMEA Error Codes
Example: Error message 1errorSD on an 8 Channel NMEA Module would indicate that the data on input
Port 6 has the wrong data format or speed or is corrupt.
