Rutter VDR-100G2 - Technical Specifications; Power Consumption; DPU and DAU Specifications

VDR-100G2/G2S Operation User Manual 19
RUT-UM-02-002_Rev. 2.0
2 TECHNICAL SPECIFICATIONS
The following tables contain a summary of the technical specifications for the Rutter VDR-100G2 system
components:
Power Consumption
Normal Operating Current (approx)
1.1 A @ 220VAC (approx. 250 Watts)
2.1 A @ 120VAC (approx. 250 Watts)
11 A @ 24VDC
Maximum Current Draw (approx)
2.9 A @ 220VAC (during battery charge)
5.3 A @ 120VAC (during battery charge)
26.7 A @ 24VDC (during battery charge)
Recommended Ship Main Breaker
10 A @ 220VAC
15 A @ 120VAC
30 A @ 24VDC
DPU Specifications
Weight 43.2Kg
Dimensions 350 x 400 x 400mm (H x W x D)
Input Power 85 -264 VAC 50-60Hz (optional 24VDC)
Output Power
24VDC to FRM, optional DAU, Alarm Module, optional Remote Storage and
optional interfaces
Data Ports
Ethernet input from Audio, Video, and NMEA Modules
Ethernet Output to FRM
Ethernet Output to Optional Remote Storage and/or Download/Playback PC
RS232 Input/Output for Alarm Module
RS232 Input/Output for Power Control Module
Battery Backup Power 2 Hrs @ -15 Deg C for Audio system, Alarm Module, DMM, and FRM
Data Storage Capacity
24 hours of most current data
(Units prior to S/N: 20105020037, with the exception of S/N: 20105020034, have a
standard storage capacity of 12 hours of current data)
Plus multiple secured data sets and 30 days extended NMEA
4GB Download USB 2.0 Drive
