VDR-100G2/G2S Operation User Manual 20
RUT-UM-02-002_Rev. 2.0
DAU Specifications (the DAU Cabinet is optional and not applicable to VDR-100G2S)
Weight 16.8Kg
Dimensions 400 x 600 x 150mm (H x W x D)
Input Power 24VDC from DPU
Output Power 24VDC to remote interfaces (Max 6A)
Audio Input Capacity
8, 12, or 16 Audio inputs
Flexible Microphone and VHF/Line level combinations
Video Input Capacity
Up to 4 video input ports
170MHz pixel rate with 2 megapixels input resolution, up to 340MHz pixel rate
captured from two consecutive frames with clock inversion (Includes 1600 x 1200 x
75 Hz & 1280 x 1024 x 85 Hz)
24 bit RGB; monochrome
H and V sync input
Data Input Capacity
8 or 16 NMEA 0183/IEC61162 Data Input ports.
Interfaces for converting non-standard signal formats are to be DIN rail mounted as
close to the signal source as practical. The following interfaces are available for
remote mounting:
DataAnalog analog signals interface
DataDiscrete contact signal interface
DataGyro gyrocompass interface
DataSynchro synchro type gyrocompass interface
DataSplitter NMEA splitter interface
DataProtocol protocol conversion interface
