FRM/SFRM Specifications
Weight
L3 HVR-02 Fixed FRM Capsule: 10.9kg
L3 SVR-02 Fixed SFRM Capsule:10.4kg
JoTron Float-Free SFRM Capsule: 3.5kg;
Rutter-ACR Float-Free SFRM Capsule (EPIRB Only): 1.021kg
Rutter FRM (RUT-02447) Fixed Capsule: 18kg
Dimensions
L3 HVR-02 Fixed FRM Capsule:
Height: 218.3mm, Diameter: 206.5mm, Base Width: 182.39mm
L3 SVR-02 Fixed SFRM Capsule:
Height: 215.17mm, Diameter: 206.5mm, Base Width: 182.39mm
JoTron Float-Free SFRM Capsule:
Height: 695mm, Depth: 226mm, Width: 205mm
Rutter-ACR Float-Free SFRM Capsule (EPIRB Only):
Height: 178mm, Depth: 108mm, Width: 92mm
Rutter FRM (RUT-02447) Fixed Capsule:
Height: 350mm, Diameter: 220mm
Input Power 24VDC
Memory Type
L3 HVR-02 Fixed FRM Capsule: Solid State
L3 SVR-02 Fixed SFRM Capsule: Solid State
JoTron Float-Free SFRM Capsule: Solid State
Rutter-ACR Float-Free SFRM Capsule: Solid State
Rutter FRM (RUT-02447) Fixed Capsule: Solid State
Capacity 12-hour minimum ( 1.75GB )
OAU Specifications
Weight 1.4Kg
Dimensions
With front mounting plate: 144 x 144 x 52.3mm
Without front mounting plate: 136.6 x 136.6 x 50mm
Input Power 24VDC
Audible Alarm 60dBA
