VDR-100G2/G2S Operation User Manual 22
RUT-UM-02-002_Rev. 2.0
Indoor Microphone Assembly Specifications
Weight 0.95Kg
Dimensions Mic: 64 x 92 x 31mm / Box: 80 x 149.1 x 56.5mm
Input Power Phantom Power
Optional Outdoor Microphone Specifications
Weight 1.17Kg
Dimensions Mic: 64 x 92 x 31mm / Box: 85.1 x 129.9 x 65.7mm
Input Power Phantom Power
Optional RSM Specifications
Weight 1.36Kg
Dimensions 35 x 127 x 214mm
Input Power 24VDC or Universal AC with external power supply
Capacity 250GB
Optional RSM 24VDC Power Supply Specifications
Weight 1.0Kg
Dimensions 138 x 166.2 x 50mm
Input Power 24VDC
