The battery connection input is floating, i.e. there is no galvanic
connection from any of the battery poles to the cabinet frame.
2.5.2 DTE Communication port
The TT-3020C Capsat Transceiver communicates with a controller
device via the standard EIA/TIA-232E ports on a female 9 pole
Sub-D connector, located on the rear panel at X3.
2.5.2.1 Baudrate and protocol settings
The TT-3020C accepts the following:
Baud rates
Baud ratesBaud rates
Baud rates Protocol settings
Protocol settingsProtocol settings
Protocol settings Handshake
HandshakeHandshake
Handshake
110 Baud 7/8 databits Hardware
150 Baud No/Even/Odd parity Using DTR and CTS
300 Baud 1/2 stopbits
600 Baud Software
1200 Baud Using XON and XOFF
2400 Baud
4800 Baud
9600 Baud
19200 Baud
38400 Baud
Table 6 Automatic baudrate settings
The serial port communication parameters are factory pro-
grammed to:
4800 Baud, 8 databits, no parity, 1 stopbit
4800 Baud, 8 databits, no parity, 1 stopbit4800 Baud, 8 databits, no parity, 1 stopbit
4800 Baud, 8 databits, no parity, 1 stopbit
Please see section 4.2.2 to alter baudrate and protocol settings.
