Sailor H2095C - Table 9 Printer Port (X5) Pin Assignment

Installation - TT-3020C
Installation - TT-3020CInstallation - TT-3020C
Installation - TT-3020C Connectors
ConnectorsConnectors
Connectors
Page
PagePage
Page 2-16
2-162-16
2-16 25-Jul-00
25-Jul-0025-Jul-00
25-Jul-00
Pin Name Signal Description
1 STRB Strobe
2 DAT0 Data Bit 0
3 DAT1 Data Bit 1
4 DAT2 Data Bit 2
5 DAT3 Data Bit 3
6 DAT4 Data Bit 4
7 DAT5 Data Bit 5
8 DAT6 Data Bit 6
9 DAT7 Data Bit 7
10 ACKN Acknowledge
11 BUSY Printer Busy
12 PE Paper End (out of paper)
13 SEL Printer Selected
14 ALFD Auto Line Feed
15 ERR Printer Error
16 INIT Initialise Printer
17 SLCT Select Printer
18 GND Ground
19 GND Ground
20 GND Ground
21 GND Ground
22 GND Ground
23 GND Ground
24 GND Ground
25 GND Ground
Table 9 Printer port (X5) pin assignment
