Power requirements Receive
mode
Transmit
mode
TT-3020C Capsat Transceiver incl. TT-3005M
antenna.
Floating DC (10-32V).
3.8W 80W
Max.
90W
TT-3020C Capsat Transceiver Incl. TT-3005M
Antenna & GPS. Floating DC (10-32V).
4.4W 80W
Max.
90W
TT-3606E Message Terminal, incl. Keyboard.
Floating DC (10.5 - 32V)
13 W
average
20 W
peak
TT-3608A Printer 220AC or option 010 DC
supply floating (10.5 - 32V)
33W
TT-3042D Remote Alarm Distress Box with
printer
2.5 W
standby
7 W
printing
TT-3608G Remote Printer Unit 2.5 W
standby
7 W
printing
Table 11 Capsat System component power requirements
3.1.1 Fuses
In case you experience that a fuse needs replacement, please
check that the equipment has not been exposed to physical dam-
age before fuse replacement takes place.
WARNING
WARNINGWARNING
WARNING
To avoid hazardous electrical shock, do not perform electrical
tests if there is any sign of shipping damage to any portion of
the front or rear panel or the outer cover. Read the safety
summary at the front of this manual before installing or
operating the TT-3020C Transceiver
