TT-3005M
Maritime Antenna
Inmarsat-C/GPS omnidirectional
antenna, RHC polarised.
G/T: -23 dB/K at 5° elevation
EIRP: 14 dBW ± 2dB at 5° elevation.
Temperature: -35°C to 55°C operating,
-40°C to 80°C storage.
Dimensions (H x D): 178 mm x 122 mm.
Weight: 0.90 kg.
Maximum transmission
length
32 Kbyte.
Solar Radiation Max. flux density 1200W/m2.
Relative Humidity 95% non-condensing at 40°C.
Precipitation Up to 100 mm/hour, droplet size 0.5 to
4.5 mm
Ice Up to 25 mm.
Wind Up to 200 km/hour.
Vibration Operational Random 5-20 Hz: 0.005 g
2
/Hz
20-150 Hz: -3dB/oct. (0.5g RMS).
Vibration Survival Random 5-20 Hz: 0.05 g
2
/Hz
20-150 Hz: -3dB/oct. (1.7g RMS).
Shock Half sine 20g/11ms
Antenna Mounting 1” tube mounting
Transceiver coax cable 0.7Ohm max DC resistance (shield +
inner conductor)
17dB max RF insertion loss at 1.6GHz.
100 meter max cable length. TNC
connectors.
Table 14 TT-3005M technical specifications.
3.3.1.1 Antenna connector
"N" and ‘’TNC’’ type connectors are available from manufacturers
like:
Suhner, Radial, Omnispectra, Kings, etc.
