2.6.1 GPS specifications
The GPS receiver module tracks 12 GPS satellites . The following
power-up time estimates are available, from field test.
Start state GPS 25
All data known 15 sec
Position, time and almanac known 45 sec
Almanac known 90 sec
No data known 5 min
Field test cold start same position
after 8 hours off
Update rate 1 second (typical)
Position accuracy 15m RMS (100m with
Selective Availability on)
Typical velocity accuracy 0.2m/s RMS
Table 10 GPS Specifications
2.7 Mounting bracket
The TT-3020C Capsat Transceiver is supplied with an universal
mounting plate (41-107093-A) which allows mounting to e.g. a ta-
ble.
