Position Setting Fact.
Address
1-3 off,off,off: 1 1
off,off,on: 2
off,on,off: 3
off,on,on: 4
on,off,off: 5
on,off,on: 6
on,on,off: 7
on,on,on: 8
Printing Direction
4 on: Reverse off
off: Normal
5 Not Used
NMEA/Aux.Port
6 on:
NMEA 0183
1
NMEA
off:
Serial data
2
Dot Energy
7 on: High High
off: Normal
Printing Width
8 on: 40 Chars per line 80
off: 80 Chars per line
Table 23 TT-3608G DIP switch settings.
1
Jumper W2 and W9 should be in position 1-2 (low) in Rx mode to
achieve optical isolation, else position 2-3 (high).
2
Jumper W2 and W9 must be in position 2-3 (high).
