Antenna Interface Standard 50 Ohm female TNC-connector.
Max 70m cable with TT-3005A antenna or
max 100m cable with TT-3001B or TT-
3005M antenna.
Terminal Interface EIA/TIA-232-E DTE interface. CCITT
Rec.V.24/28, 110-38400 Baud IA-5 code,
DB-9F connector.
Printer Interface Standard parallel Centronics, DB-25F
connector. IEEE P1284-I
I/O Interface: NMEA-0183 version 2.1 interface and
multidrop addressing, max.100 meter
cable.
ArcNet 156Kbit token based I/O, max
100 meter cable (ATA/ANSI 878.1)
Four dedicated In/Out pins and two
Inputs pins to the TT-3042C Remote
Alarm/Distress Box.
DB-15F connector
System Set-up Flash memory
DC Power Source 10.5 to 32 V floating DC
RX: 3.8 W with GPS 4.4W
TX: Typ. 80 W max. 90W
Fuse 12A T
Ambient Temperature -25°C to 55°C operating
-40°C to 80°C storage.
Electronic Unit Mounting Mounting bracket.
Dimensions H x W x D 50mm x 180mm x 165mm. ( car radio
standard ISO7736 )
Weight 1.3 kg
Table 1 TT-3020C technical specifications.
Document Nr: I-MA-3010.68-5510-762-IVT-312
