SAJ 8000B series User Manual

-
11
-
8000B Series
I/O
Characteristics
Input
Frequency
Resolution
Analog setting:max. frequency × 0.1%;
Digital setting:0.01Hz
Output Voltage 0~rated input voltage
Output
Frequency
Range
0.00~600Hz
Digital Input
Terminals
Six (programmable)
Analog Input
Terminals
AVI:0~10V; ACI:0~10V or 0/4~20mA
Relay Output 1 relay output
Open Collector
Output
Provide 1 channel programmable
Analog Output
0.75~2.2kW:FM:0~10V; AM:0/4~20mA
4~400kW:FM:0~10V; AM:0~10V / 0/4-20mA
Basic
Functions
Frequency
Setting
Channels
Three channels:setting by keyboard, setting by control
terminals, setting by serial communication interface.
These channels can be switched.
Frequency
Setting Source
8 methods including panel knob setting, UP/DOWN key
setting and PID setting, etc.
Simple PLC
Function
16 steps speed control can be carried out by simple PLC
function inside and terminals.
PID Function
Close-loop controlling system can be carried out by PID
inside.
Swing
Frequency
Function
Suitable for textile and chemic al f iber machine by
controlling the triangular frequency.
AVR Function
Automatically keep the output voltage constant when
power supply is not stable.
