18
-
8000B Series
Chapter 2 Mechanical and Electric Installation
2.1 Mechanical Installation
2.1.1 Installation Environment
The ambient temperature exerts great influences on the service life of the
inverter and is not allowed to exceed the allowable temperature range
(-10
℃
to 40
℃
).
The inverter should be mounted on the surface of incombustible articles, with
sufficient spaces nearby for heat sinking. The inverter is easy to generate
large amount of heat during operation. The inverter should be mounted
vertically on the base with screws.
The inverter should be mounted in the place without vibration or with vibration
of less than 0.6G
The inverter should be mounted in locations away from direct sunlight, high
humidity, condensate, corrosive gas, explosive gas, oil dirt, dust, and metal
powder etc.
2.1.2 Installation Space and Distance
When take up-down installation, air deector should be installed between
upper inverter and lower inverter.
