SAJ 8000B series User Manual

-
15
-
8000B Series
1.5.2.2 Dimensions Table
Inverter Model
Installation
Dimensions
(mm)
Appearance Dimensions (mm)
Hole
Diameter
(mm)
A B H H1 W W1 D
8000B-2SR75GB
92 142.7 151.7 101 126.8 ø58000B-2S1R5GB
8000B-2S2R2GB
8000B-4TR75GB
92 142.7 151.7 101 126.8 ø58000B-4T1R5GB
8000B-4T2R2GB
8000B-4T004GB/4T5R5PB
144.4 237 249.5 155.5 159.5 ø5.98000B-4T5R5GB/4T7R5PB
8000B-4T7R5GB
8000B-4T011GB/4T015PB
156.6 378.3 364 396 214 221.7 190.5 ø68000B-4T015GB/4T18R5PB
8000B-4T18R5GB
8000B-4T022G/4T030P
235 447 424 463 285 289.6 210.3 ø78000B-4T030G/4T037P
8000B-4T037G
8000B-4T045G/4T055P
260 580 544 595.5 380 390 284.8 ø10
8000B-4T055G/4T075P
8000B-4T075G/4T093P
343 674 650 701.5 473 485 318 ø108000B-4T093G/4T110P
8000B-4T110G
8000B-4T132G/4T160P
449 902.5 927 1359 580 384 ø108000B-4T160G/4T185P
8000B-4T185G
8000B-4T200G/4T220P
420 1162 1131.5 1481.6 680 400.5 ø128000B-4T220G/4T250P
8000B-4T250G/4T280P
8000B-4T280G/4T315P
520 1300 1355 1765 800 392.5 ø14
8000B-4T315G
8000B-4T350G
8000B-4T400G
