SAJ 8000B series User Manual

-
54
-
8000B Series
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modi-
cation
Type
F8.25
Inverter rated
power
0.4~700.0kW 0.1kW
Dened
by
inverter
model
◎
F8.26
Inverter rated
current
0.0~2000A 0.1A
◎
F8.27
Linear speed
display
coefficient
0 .1~ 9 9 9 . 9% ( l i nea r s p e e d=
mechanical speed * F8.27)
0.1% 1.0%
○
F8.28
~
F8.29
Reserved
F9 Group: PID parameters
F9.00
PID setting
source
0:Keypad (F9.01)
1:Analog terminal AVI
2:Analog terminal ACI
3:Communication interface
4: M uli-f un c ti on d ig it a l i np ut
terminals
0
○
F9.01
Keypad PID
preset
0.0%~100.0% 0.1% 0.0%
●
F9.02
PID feedback
source
selection
0:Analog terminal AVI
1:Analog terminal ACI
2:AVI+ACI
3:Communication interface
0
○
F9.03
PID output
characteristic
0: Positive
1: Negative
0
○
F9.04
Proportional
gain (Kp)
0.00~100.0 0.01 0.10
○
F9.05
Integral time
(Ti)
0.01~10.00s 0.01s 0.10s
○
F9.06
Differential time
(Td)
0.00~10.00s 0.01s 0.00s
○
