SAJ 8000B series User Manual

-
21
-
8000B Series
2.2.3 Recommended Table of Reactor
Inverter Model
AC Reactor at the
Input Side
AC Reactor at the
output Side
DC Reactor
Voltage
Current
(A)
Inductance
(mH)
Current
(A)
Inductance
(mH)
Current
(A)
Inductance
(mH)
8000B-2SR75GB 2 7 2 7 3 28
220V8000B-2S1R5GB 5 3.8 5 3.8 6 11
8000B-2S2R2GB 7.5 2.5 7.5 2.5 6 11
8000B-4TR75GB 2 7 2 3 3 28
380V
8000B-4T1R5GB 5 3.8 5 1.5 6 11
8000B-4T2R2GB 7 2.5 7 1 6 11
8000B-4T004GB/4T5R5PB 10 1.5 10 0.6 12 6.3
8000B-4T5R5GB/4T7R5PB 15 1.0 15 0.25 23 3.6
8000B-4T7R5GB 20 0.75 20 0.13 23 3.6
8000B-4T011GB/4T015PB 30 0.60 30 0.087 33 2
8000B-4T015GB/4T18R5PB 40 0.42 40 0.066 33 2
8000B-4T18R5GB 50 0.35 50 0.052 40 1.3
8000B-4T022G/4T030P 60 0.28 60 0.045 50 1.08
8000B-4T030G/4T037P 80 0.19 80 0.032 65 0.80
8000B-4T037G 90 0.16 90 0.030 78 0.70
8000B-4T045G/4T055P 120 0.13 120 0.023 95 0.54
8000B-4T055G/4T075P 150 0.10 150 0.019 115 0.45
8000B-4T075G/4T093P 200 0.08 200 0.014 160 0.36
8000B-4T093G/4T110P 250 0.06 250 0.011 180 0.33
8000B-4T110G 250 0.06 250 0.011 250 0.26
8000B-4T132G/4T160P 290 0.04 290 0.008 250 0.26
8000B-4T160G/4T185P 330 0.04 330 0.008 340 0.18
8000B-4T185G 400 0.04 400 0.005 460 0.12
8000B-4T200G/4T220P 490 0.03 490 0.004 460 0.12
8000B-4T220G/4T250P 490 0.03 490 0.004 460 0.12
8000B-4T250G/4T280P 530 0.03 530 0.003 650 0.11
8000B-4T280G/4T315P 600 0.02 600 0.003 650 0.11
8000B-4T315G 660 0.02 660 0.002 800 0.06
8000B-4T350G 400*2 0.04 400*2 0.005 460*2 0.12
8000B-4T400G 490*2 0.03 490*2 0.004 460*2 0.12
