SAJ 8000B series - F5 Group: Input Terminals Parameters

-
44
-
8000B Series
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modi-
cation
Type
F4.12
Low-frequency
threshold of
restraining
oscillation
0~10 2
○
F4.13
High-frequency
threshold of
restraining
oscillation
0~10 0
○
F4.14 Reserved
F4.15
Boundary
frequency of
restraining
oscillation
0.00Hz~F0.10 (Maxi. frequency) 0.01Hz 30.00Hz
○
F4.16 Reserved
F4.17
AVR function
selection
0:Invalid
1:Valid all the time
2 : O n l y i n v a l i d d u r i n g
deceleration
1
○
F5 Group: Input Terminals Parameters
F5.00
M1 terminal
function
0:Invalid
1:Forward run (FWD)
2:Reverse run (REV)
3:3-wire control
4:Forward jog run (FJOG)
5:Reverse jog run (RJOG)
6: Coast to stop
7: Fault reset (RESET)
8: Pause running
9: External fault input N. O.
10: UP Key command
11: DOWN Key command
12: Clear UP/DOWN setting
1
●
F5.01
M2 terminal
function
2
●
