SAJ 8000B series User Manual

-
10
-
8000B Series
1.4 Specications of 8000B Series Inverter
Characteristics
of Controlling
Control Mode Sensorless vector control V/F control
Start Torque 0.5Hz 150% 0.5Hz 100%
Rotation Speed
Ratio
1:200 1:100
Precision
of Speed
Regulation
±0.5% ±1.0%
Overload
Capability
M o d e l G :1 5 0 % a b o ve t h e r a t e d c u r r e n t f o r 6 0
seconds;180% above the rated current for one second.
M o d e l P :1 2 0 % a b o v e t h e r a t e d c u r r e n t f o r 6 0
seconds;150% above the rated current for one second.
V/F curve
Three selection type: Linear t ype,Square type and
Multipoint type.
DC Brake
DC brake frequency:0.00~max. frequency;
brake time:0.1~50.0s;
Brake cur rent:0 ~15 0 % of rated c ur r ent(mode l G);
0~100% of rated current:model P);
Brake waiting time:0.0~50.0s
Jog Operation
Jog frequency range:0.00-max.frequency;
Accel./Decel. time of jog operation:0.1~3600s.
Accel./Decel.
Time
Accel./Decel. time range:0.1~3600s
Torque
Boosting
Manual setting:0.1~30.0%; Automatic setting:0.0
I/O
Characteristics
Start
Frequency
0.50~10Hz
Input Voltage 220V/380V ± 15%
Input
Frequency
50/60Hz,fluctuation range:±5%
