SAJ 8000B series User Manual

-
17
-
8000B Series
1.6 Selection Instruction Table of Brake Resistor and Brake Unit
Inverter Model
Recommended
Power of Brake
Resistor
Recommended
Resistance Value
of Brake Resistor
Brake Unit
8000B-2SR75GB 80W ≥150Ω
Standard
Accessory
Inside
8000B-2S1R5GB 100W ≥100Ω
8000B-2S2R2GB 100W ≥70Ω
8000B-4TR75GB 150W ≥300Ω
8000B-4T1R5GB 150W ≥220Ω
8000B-4T2R2GB 250W ≥200Ω
8000B-4T004GB/4T5R5PB 300W ≥130Ω
8000B-4T5R5GB/4T7R5PB 400W ≥90Ω
8000B-4T7R5GB 500W ≥65Ω
8000B-4T011GB/4T015PB 800W ≥43Ω
8000B-4T015GB/4T18R5PB 1000W ≥32Ω
8000B-4T18R5GB 1300W ≥25Ω
8000B-4T022G/4T030P 1500W ≥22Ω
Additional
Accessory
(external)
8000B-4T030G/4T037P 2500W ≥16Ω
8000B-4T037G 3.7 kW ≥16.0Ω
8000B-4T045G/4T055P 4.5 kW ≥16Ω
8000B-4T055G/4T075P 5.5 kW ≥8Ω
8000B-4T075G/4T093P 7.5 kW ≥8Ω
8000B-4T093G/4T110P 4.5 kW×2 ≥8Ω×2
8000B-4T110G 5.5 kW×2 ≥8Ω×2
8000B-4T132G/4T160P 6.5 kW×2 ≥8Ω×2
8000B-4T160G/4T185P 16kW ≥2.5Ω
8000B-4T185G 20 kW ≥2.5Ω
8000B-4T200G/4T220P 20 kW ≥2.5Ω
8000B-4T220G/4T250P 22 kW ≥2.5Ω
8000B-4T250G/4T280P 12.5 kW×2 ≥2.5Ω×2
8000B-4T280G/4T315P 14kW×2 ≥2.5Ω×2
8000B-4T315G 16kW×2 ≥2.5Ω×2
8000B-4T350G 17kW×2 ≥2.5Ω×2
8000B-4T400G 14 kW×3 ≥2.5Ω×3
