SAJ 8000B series User Manual

-
50
-
8000B Series
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modi-
cation
Type
F7 Group: Display Interface Parameters
F7.00 User password 0~9999 0
○
F7.01 Reserved
F7.02 Reserved
F7.03
REV/JOG
key function
selection
0:Switch display status
1:Clear UP/DOWN setting
2:Reverse running
3:Forward jog running
4:Quick debugging mode
2
●
F7.04
Stop function
selection of
STOP/RESET
key
0:Only valid for keypad setting
1:Valid for both keypad setting
and terminals setting
2:Valid for both keypad setting
and c ommunication inter face
setting
3:Valid for all control mode
0
○
F7.05 Reserved
F7.06
Running
status display
selection 1
0~0xFFFF
BIT0:Running frequency
BIT1:Setting frequency
BIT2:DC bus voltage
BIT3:Output voltage
BIT4:Output current
BIT5:Running speed
BIT6:Linear speed
BIT7:Reserved
BIT8:Reserved
BIT9:PID setting value
BIT10:PID feedback value
BIT11:Input terminals status
BIT12:Output terminals status
BIT13:Reserved
BIT14:Counter value
BIT15:Current step of multi-step
speed and PLC
35
○
