SAJ 8000B series User Manual

-
27
-
8000B Series
3.2 Terminal Descriptions of Main Circuit and Control Circuit
3.2.1 Main Circuit Terminals:
(1) Main circuit terminals (0.75kW~2.2kW (model G) with built-in brake unit)
(2) Main circuit terminals (4kW~7.5kW (model G) with built-in brake unit)
(3) Main circuit terminals (11kW~18.5kW (model G) with built-in brake unit)
(4) Main circuit terminals (22kW~37kW (model G))
(5) Main circuit terminals (45kW~110kW (model G))
(6) Main circuit terminals (132kW~400kW (model G))
