SAJ 8000B series User Manual

-
20
-
8000B Series
2.2.2 Recommended Table of External Electrical Parts
Inverter Model
Circuit
Breaker
(MCCB)
(A)
Recommended
Contactor (A)
Conducting
Wire of
Main Circuit
at the Input
Side (mm
2
)
Conducting
Wire of
Main Circuit
at the Input
Side (mm
2
)
Conducting
Wire of
Control
Circuit
(mm
2
)
8000B-2SR75GB 16 10 2.5 2.5 1.0
8000B-2S1R5GB 20 16 4.0 2.5 1.0
8000B-2S2R2GB 32 20 6.0 4.0 1.0
8000B-4TR75GB 10 10 2.5 2.5 1.0
8000B-4T1R5GB 16 10 2.5 2.5 1.0
8000B-4T2R2GB 16 10 2.5 2.5 1.0
8000B-4T004GB/4T5R5PB 25 16 4.0 4.0 1.0
8000B-4T5R5GB/4T7R5PB 32 25 4.0 4.0 1.0
8000B-4T7R5GB 40 32 4.0 4.0 1.0
8000B-4T011GB/4T015PB 63 40 4.0 4.0 1.0
8000B-4T015GB/4T18R5PB 63 40 6.0 6.0 1.0
8000B-4T18R5GB 100 63 6.0 6.0 1.5
8000B-4T022G/4T030P 100 63 10 10 1.5
8000B-4T030G/4T037P 125 100 16 10 1.5
8000B-4T037G 160 100 16 16 1.5
8000B-4T045G/4T055P 200 125 25 25 1.5
8000B-4T055G/4T075P 200 125 35 25 1.5
8000B-4T075G/4T093P 250 160 50 35 1.5
8000B-4T093G/4T110P 250 160 70 35 1.5
8000B-4T110G 350 350 120 120 1.5
8000B-4T132G/4T160P 400 400 150 150 1.5
8000B-4T160G/4T185P 500 400 185 185 1.5
8000B-4T185G 600 600 150*2 150*2 1.5
8000B-4T200G/4T220P 600 600 150*2 150*2 1.5
8000B-4T220G/4T250P 600 600 150*2 150*2 1.5
8000B-4T250G/4T280P 800 600 185*2 185*2 1.5
8000B-4T280G/4T315P 800 800 185*2 185*2 1.5
8000B-4T315G 800 800 150*3 150*3 1.5
8000B-4T350G 800 800 150*4 150*4 1.5
8000B-4T400G 1000 1000 150* 150*4 1.5
