SAJ 8000B series - FC Group: RS485 Communication Parameters

-
59
-
8000B Series
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modi-
cation
Type
FB.07
Clear up
counting meter
value
0:Invalid
1:Valid
0
○
FB.08
Counter value
setting
FB.09~9999 0
○
FB.09
Designated
counter value
0~FB.08 0
○
FB.10
Counting meter
length
0 : A c t u a l c o u n t i n g l e n g t h =
displayed length* 1m
1: A c t u a l c o u n t i n g l e n g t h =
displayed length* 10m
0
○
FC Group: RS485 Communication Parameters
FC.00 Local address
1~247, 0 refers to the broadcast
address
1
○
FC.01
Baud rate
selection
0:1200BPS
1:2400BPS
2:4800BPS
3:9600BPS
4:19200BPS
5:38400BPS
3
○
FC.02 Data bit check
0: No check (N, 8, 1) for RTU
1: Even parity check (E, 8, 1) for
RTU
2: Odd parity check (0, 8, 1) for
RTU
3: No check (N, 8, 2) for RTU
4: Even parity check (E, 8, 2) for
RTU
5: Odd parity check (0, 8, 2) for
RTU
0
○
FC.03
Communication
response delay
time
0~200ms 1ms 5ms
○
